Features:
- Screw down solderless wire connection for easy/reliable installation and quick pickup swaps!
- Vintage quality USA branded components (Switchcraft, Mojotone, CRL, and CTS)!
- USA made CRL Switch! It's the most reliable and smoothest feeling switch ever made and hasn't changed since the 50's.
- Smooth custom taper made to Mojotone specifications, our CTS industrial potentiometers come with solid brass bushings and the tightest tolerances available.
- Pre-wired Switchcraft mono jack with pre-tinned push-back cloth covered wire.
- Transparent and musical Mojotone Dijon Capacitor designed specifically for guitar and bass tone controls.
- Switchable between our most popular Blender or Standard mod wiring.
- Optional volume mod (on/off switch) for retaining high end detail while rolling the volume back.
- Easily serviceable for any future component swaps or maintenance.
- Screwdriver included.
Blender Control Functions: Unlike standard wiring, Blender wiring adds the option for all 3 pickups to be on at once and the ability to combine the neck and bridge pickups as much as you want.
Master Volume: Top Knob
Master Tone: Middle Knob
Blender Control: Bottom Knob
Blender knob on 10
Position 1: Bridge
Position 2: Bridge and Middle
Position 3: Middle
Position 4: Middle and Neck
Position 5: Neck
Blender knob on 0
Position 1: Bridge (with Neck blended in)
Position 2: Bridge and Middle (with Neck blended in)
Position 3: Middle
Position 4: Middle and Neck (with Bridge blended in)
Position 5: Neck (with Bridge blended in)
Standard Mod Control Functions: Standard strat wiring with no tone control for the middle pickup only. This reduces the load on positions 2 and 4 to only one tone pot, giving you a more clear and open tone when combining the neck/middle or bridge middle pickups. AKA the “EJ Mod”.
Master Volume: Top Knob
Neck Tone: Middle Knob
Bridge Tone: Bottom Knob
Standard Switching
Position 1: Bridge
Position 2: Bridge and Middle
Position 3: Middle
Position 4: Middle and Neck
Position 5: Neck
Included:
- (3) CTS 500k vintage taper split shaft potentiometers
- (1) CRL USA 5-way lever switch (Switch tip sold separately)
- (1) Prewired Switchcraft USA mono input jack
- (1) Mojotone Dijon Tin Foil .047uf capacitor
- (1) Optional Treble Bleed (Preserves highs on volume control)
- (1) Detailed wiring diagram and easy to understand instructions
Note:
Guitars made overseas may require you to enlarge the holes for the larger US spec pots to fit. You will also need to change the metric knobs to inch sized 24-knurl push-on knobs and the switch tip. See related items. If you have a non-Fender brand Strat® or overseas made Strat®, please verify the fit before purchasing.
Prepare to turn your Strat into a musical time machine! Mojotone was lucky enough to get our hands on an original 1962 Fender Stratocaster, bought by Wayne Powell Crandell in 1962 and left to his son upon his passing. This guitar perfectly exemplified the simple elegance of early Stratocasters, marked with the scars of forgotten adventures, and one listen let us know that it still had plenty of stories to tell. (See the video here.) So naturally, Mojotone was inspired to do what we do best: recreate this sound so that you can have it too!
To capture the magic of 1962, we made everything exactly to the specs that Fender used at the time: hand-beveled Alnico 5 rod magnets, vulcanized fiberboard flatwork, a non-RWRP middle pickup, and lightly wax potted coils hand-wound with 42-gauge Formvar coil wire. And now they are available in an easy-to-install pre-wired pickguard, with a musical Mojotone Dijon .047uF tone capacitor, Mojotone/CTS Vintage Taper potentiometers and a durable CRL 5-way switch for standard access to every position. Plus, you can choose the color of the pickguard and pickup covers!
Of course, components mean nothing if the tone isn't there, so we put a great deal of time and effort into giving these the sound and feel of original 1962 Strat pickups. It is like being transported back to the year when John Glenn first orbited the Earth, the Twist was the latest and greatest dance craze, and the world was about to hear Bob Dylan, The Beach Boys and The Beatles for the first time. For many of us, buying an actual 1962 Strat is a virtual impossibility, but our Crandellcaster 1962 Clone Strat Standard Prewired Pickguard will get you as close to that tone as you can get without robbing a museum.
René Martinez was originally Stevie Ray Vaughan's hand-picked guitar tech. He also worked with Eddie Brickell, Mick Jones of Foreigner, Clint Black, Prince, The Moody Blues, Jimmie Vaughan, Carlos Santana, and currently John Mayer. You can find out more about his amazing career here. Mojotone is excited and honored to have worked with such a renowned luthier to develop our René Martinez "Texas" Strat® Pickups.
The magnets are customized Alnico III in the neck and middle and Alnico V in the bridge to give a full and balanced tone. You get that clean, ultra clear neck and middle tone that lets your amp shape your tone, while the bridge pickup is hotter with more girth and punch, and a sonic clarity that cuts through with attitude. The coils are calibrated from neck to bridge for an even volume throughout the switching.
Be the first in your town to own a set designed by such an acclaimed luthier. These come stock with staggered magnets with a raised D specifically for unwound 3rd string sets. RWRP middle position to be hum-cancelling in positions 2 and 4. Vacuum potted coils.
All of our pickups are proudly built in Burgaw, NC!
Click here for current lead times
