#4014101

Jensen P8R 25W 8'' Replacement Alnico Speaker 4 OHM

The 25 watt P8R is an alnico magnet speaker that remains warm with emphasis on the highs. This speaker produces a nice warm fuzz when driven by an amplifier.
$114.99
Shipping calculated at checkout.
Free U.S. shipping over $99
Real support from real techs
Designed, tested, and trusted in-house
SPECS

WEIGHT:4lb

Overall Diameter: 8 in

Voice Coil Diameter: 1.00 in

Magnet Weight: 7.00 oz

Overall Weight: 2.64 lbs

Flux Density: 0.96 T Thiele-Small Parameters Voice Coil DC Resistance: 6.60 Ω

Resonance Frequency: 135.0 Hz

Mechanical Q Factor: 8.67

Electrical Q Factor: 2.30

Total Q Factor: 2.28

Mechanical Moving Mass: 8.8 g

Mechanical Compliance: 159 µm/N

Force Factor: 3.99 Wb/m

Acoustic Volume: 10.3 lt.

Linear Displacement: 1.00 mm

Reference Efficiency: 0.95%

Diaphragm Area: 213.8 cm2

Electrical Resistance: 27.0 Ω

Voice Coil @ 1kHz: 0.36 mH Constructive Characteristics Magnet: Alnico

Voice Coil Winding: Copper

Voice Coil Former: Epotex

Cone: Paper

Surround: Integrated Paper

Dust Dome: Solid Paper

Basket: Pressed Sheet SteelElectrical Characteristics Nominal Impedance: 4 Ω

Rated Power: 25 W

Musical Power: 50 W

Sensitivity@1W,1m: 91.8 dB
